ST STDES-50W2CWBC - Page 17

Item Q.ty Ref. Part/value Description Manufacturer Order code
17 2
C209
C231
5.6 nF, 0603, 100 V, ±10 %,
X7R, SMD
Capacitors
Kemet or
generic
C0603C562K5RACTU
18 1
R300
R408
0.010R, 1 W, 2512, 1 W, ±0.1
%, SMD
Resistors
Vishay
Precision
Group Foil
Resistors
Y14870R01000B9R
19 12
R106-108
R220-221
R224
R301-302
R400
R403-404
R407
0 R, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-070RL
20 1 R200
0R1, 0402, 1/16 W, ±5 %,
SMD
Resistor
Yageo or
generic
RL0402JR-070R1L
21 1 R231
1.2 K, 0402, 1/16 W, ±0.1 %,
SMD
Resistor
Yageo or
generic
RE0402BRE071K2L
22 12
R202
R204
R208-209
R229
R303-304
R411-415
10 K, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-0710KL
23 7
R101-102
R201
R219
R305-307
10 R, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-0710RL
24 1 R410
100 K, 0402, 1/16 W, ±5 %,
SMD
Resistor
Yageo or
generic
RC0402JR-07100KL
25 4
R416
R421
R423
R425
10K, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-0710KL
26 2
R203
R210
150 K, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-07150KL
27 3
R212
R225-226
2.2 R, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-072R2L
28 2
R218
R222
3.3 K, 0402, 1/16 W, ±1 %,
SMD
Resistors
Yageo or
generic
RC0402FR-073K3L
29 2
R230
R234
330 K, 0402, 1/16 W, ±0.1 %,
SMD
Resistors
Yageo or
generic
RE0402BRE07330KL
30 3
R227-228
R237
4.7 K, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-074K7L
31 1 R233
5.6K, 0402, 1/16 W, ±0.1 %,
SMD
Resistors
Yageo or
generic
RE0402BRE075K6L
32 2
R207
R223
47 K, 0402, 1/16 W, ±1 %,
SMD
Resistors
Yageo or
generic
RC0402FR-0747KL
33 2
R213
R217
470 K, 0402, 1/16 W, ±5 %,
SMD
RESISTOR SMD 470
K_5%_0402_1/16W
Yageo or
generic
RC0402JR-07470KL
34 2
R422
R428
47 K, 0402, 1/16 W, ±5 %,
SMD
Resistors
Yageo or
generic
RC0402JR-0747KL
35 1 R232
9.1K, 0402, 1/16 W, ±0.1 %,
SMD
Resistors
Yageo or
generic
RE0402BRE079K1L
36 2
R206
R211
47 K, 0402 NTC resistors Murata NCP15WB473F03RC
TN1399
Bill of materials
TN1399 - Rev 1
page 17/26
