5 Bill of materials
Table 4. STEVAL-ESC001V1 bill of materials
Item Q.ty Ref. Part / Value Description Manufacturer Order code
1 15
C1, C2, C5, C8, C10
C12, C13, C14, C18
C19, C23, C44, C55
C56, C57
100 nF 25 V
±10% X7R
Ceramic capacitor any
2 3 C3, C4, C11
1 nF 50 V
±10% X7R
Ceramic capacitor any
3 1 C6
4.7 µF 10 V
±10% X5R
Ceramic capacitor Murata GRM188R61A475KE15D
4 2 C7, C59
10 nF 50 V
±10% X7R
Ceramic capacitor any
5 3 C9, C43, C46
1 µF 16 V
±10% X7R
Ceramic capacitor TDK C1608X7R1C105K080AC
6 3 C15, C16, C17
15 nF 10 V
±10% X7R
Ceramic capacitor any
7 3 C20, C21, C22
680 pF 10 V
±5% C0G
Ceramic capacitor any
8 3 C24, C25, C26 100 pF ±0%
Capacitors (not
mounted)
9 1 C27
3.9 nF 50 V
±10% X7R
Ceramic capacitor any
10 1 C28
220 nF 50 V
±10% X7R
Ceramic capacitor any
11 1 C29
10 µF 50 V
±10% X5R
Ceramic capacitor any
12 1 C30
22 µF 25 V
±10% X5R
Ceramic capacitor any
13 3 C31, C42, C50
1 µF X7R 50 V
±10%
Ceramic capacitor any
14 2 C32, C35
330 µF,35 V
±20%
Electrolytic capacitor Rubycon 35ZLH330MEFC10X12.5
15 2 C33, C34
100 nF 100 V
±10% X7R
Ceramic capacitor any
16 1 C36
27 pF 50 V
±5% C0G
Ceramic capacitor any
17 2 C37, C60
4.7 nF 16 V
±10% X7R
Ceramic capacitor any
18 6
C38, C39, C47
C48, C52, C53
100 pF 16 V
±10% X7R
Ceramic capacitor any
19 3 C40, C49, C54
470 nF 25 V
±10% X7R
Ceramic capacitor any
20 3 C41, C51, C58
10 nF 100 V
±10% X7R
Ceramic capacitor any
21 1 C45
10 µF 25 V
±10% X7R
Ceramic capacitor Murata GRM21BR61E106KA73L
22 1 D1 Red LED Lite-on LTST-C193KRKT-5A
23 1 D2 Red LED Lite-on LTST-C193KGKT-5A
