Item Q.ty Ref. Part / Value Description Manufacturer Order code
49 1 R65
4.7 k 62.5 mW
±5%
SMD resistor any
50 1 R27
62 62.5 mW
±1%
SMD resistor any
51 1 R29
34.8 k 62.5
mW ±1%
SMD resistor any
52 6
R30, R35, R40
R44, R49, R55
56 0.1 W ±5% SMD resistor any
53 1 R31
300 62.5 mW
±1%
SMD resistor any
54 1 R32
8.2 k 62.5 mW
±1%
SMD resistor any
55 6
R33, R37, R42
R45, R50, R59
100 0.1 W
±5%
SMD resistor any
56 6
R34, R38, R43
R47, R51, R61
10 k 0.1 W
±5%
SMD resistor any
57 3 R36, R46, R58
1 0.125 W
±5%
SMD resistor any
58 3 R52, R53, R54
33 k 0.1 W
±1%
SMD resistor any
59 3 R56, R57, R60
4.02 k 62.5
mW ±1%
SMD resistor any
60 1 R62
169 K 62.5
mW ±1%
SMD resistor any
61 1 R63
NTC 10 K
±1%
NTC Thermistor TDK NTCG103JF103F
62 3 R64, R66, R67 0.01 3 W ±1%
10 mOhm shunt
resistor
Bourns CRA2512-FZ-R010ELF
KOA Speer TLR3APDTE10L0F50
63 1 R68
18 K 62.5 mW
±1%
SMD resistor any
64 1
TP1, TP2, TP3, TP4
TP5, TP6, TP7, TP8
TP9, TP10, TP11
TP12, TP13, TP14
TP15
SMD PAD 1
mm ±0%
Test point any
65 1 U1 CAN transceiver TI SN65HVD230D
66 1 U2 32bit MCU ST
STM32F303CBT7
67 3 U3, U4, U5
Rail-to-rail input/
output 20 MHz GBP
operational amplifiers
ST TSV991ILT
68 1 U6
3 A step-down
switching regulator
ST L7986TR
69 3 U7, U10, U11
High voltage high
and low-side driver
ST L6398D
70 1 U8
Low drop vo ltage
regulator
ST LD39050PU33R
71 1 U9
Low drop vo ltage
regulator
ST LD1117S50TR
