ST STM32G491 User Manual

RM0440 Rev 4 417/2126
RM0440 Direct memory access controller (DMA)
423
12.6.3 DMA channel x configuration register (DMA_CCRx)
Address offset: 0x08 + 0x14 * (x - 1), (x = 1 to 8)
Reset value: 0x0000 0000
The register fields/bits MEM2MEM, PL[1:0], MSIZE[1:0], PSIZE[1:0], MINC, PINC, and DIR
are read-only when EN = 1.
The states of MEM2MEM and CIRC bits must not be both high at the same time.
Bit 11 CTEIF3: transfer error flag clear for channel 3
Bit 10 CHTIF3: half transfer flag clear for channel 3
Bit 9 CTCIF3: transfer complete flag clear for channel 3
Bit 8 CGIF3: global interrupt flag clear for channel 3
Bit 7 CTEIF2: transfer error flag clear for channel 2
Bit 6 CHTIF2: half transfer flag clear for channel 2
Bit 5 CTCIF2: transfer complete flag clear for channel 2
Bit 4 CGIF2: global interrupt flag clear for channel 2
Bit 3 CTEIF1: transfer error flag clear for channel 1
Bit 2 CHTIF1: half transfer flag clear for channel 1
Bit 1 CTCIF1: transfer complete flag clear for channel 1
Bit 0 CGIF1: global interrupt flag clear for channel 1
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res.
MEM2
MEM
PL[1:0] MSIZE[1:0] PSIZE[1:0] MINC PINC CIRC DIR TEIE HTIE TCIE EN
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:15 Reserved, must be kept at reset value.
Bit 14 MEM2MEM: memory-to-memory mode
0: disabled
1: enabled
Note: this bit is set and cleared by software.
It must not be written when the channel is enabled (EN = 1).
It is read-only when the channel is enabled (EN = 1).
Bits 13:12 PL[1:0]: priority level
00: low
01: medium
10: high
11: very high
Note: this field is set and cleared by software.
It must not be written when the channel is enabled (EN = 1).
It is read-only when the channel is enabled (EN = 1).
