RM0440 Rev 4 481/2126
RM0440 CORDIC co-processor (CORDIC)
485
Note: Each DMA request must be acknowledged, as a result of the DMA performing an access to
the CORDIC_WDATA or CORDIC_RDATA register. If an extraneous access to the relevant
register occurs before this, the acknowledge is asserted prematurely, and could block the
DMA channel. Therefore, when the DMA read channel is enabled, CPU access to the
CORDIC_RDATA register must be avoided. Similarly, the processor must avoid accessing
the CORDIC_WDATA register when the DMA write channel is enabled.
17.4 CORDIC registers
The CORDIC registers can only be accessed in 32-bit word format
17.4.1 CORDIC control/status register (CORDIC_CSR)
Address offset: 0x00
Reset value: 0x0000 0050
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RRDY Res. Res. Res. Res. Res. Res. Res. Res.
ARG
SIZE
RES
SIZE
NARG
S
NRES
DMA
WEN
DMA
REN
IEN
r rw rw rw rw rw rw rw
1514131211109 8 765432 1 0
Res. Res. Res. Res. Res. SCALE[2:0] PRECISION[3:0] FUNC[3:0]
rw rw rw rw rw rw rw rw rw rw rw
Bit 31 RRDY: Result ready flag
0: No new result in output register
1: CORDIC_RDATA register contains new data.
This bit is set by hardware when a CORDIC operation completes. It is reset by hardware
when the CORDIC_RDATA register is read (NRES+1) times.
When this bit is set, if the IEN bit is also set, the CORDIC interrupt is asserted. If the
DMAREN bit is set, a DMA read channel request is generated. While this bit is set, no new
calculation is started.
Bits 30:23 Reserved, must be kept at reset value.
Bit 22 ARGSIZE: Width of input data
0: 32-bit
1: 16-bit
ARGSIZE selects the number of bits used to represent input data.
If 32-bit data is selected, the CORDIC_WDATA register expects arguments in q1.31 format.
If 16-bit data is selected, the CORDIC_WDATA register expects arguments in q1.15 format.
The primary argument (ARG1) is written to the least significant half-word, and the secondary
argument (ARG2) to the most significant half-word.
Bit 21 RESSIZE: Width of output data
0: 32-bit
1: 16-bit
RESSIZE selects the number of bits used to represent output data.
If 32-bit data is selected, the CORDIC_RDATA register contains results in q1.31 format.
If 16-bit data is selected, the least significant half-word of CORDIC_RDATA contains the
primary result (RES1) in q1.15 format, and the most significant half-word contains the
secondary result (RES2), also in q1.15 format.
