ST STM32H753I-EVAL User Manual

Features UM2199
6/69 DocID030512 Rev 1
1 Features
• STM32H753XIH6 microcontroller with 2 Mbytes of Flash memory and 1 Mbyte of RAM
in TFBGA240+25 package
• 5.7” 640x480 TFT-color LCD with touch screen
• Ethernet compliant with IEEE-802.3-2002
• USB OTG HS and FS
• I
2
C compatible serial interface
• RTC with rechargeable backup battery
• SAI Audio DAC
• ST-MEMS digital microphones
• 8-Gbyte (or more) SDIO3.0 interface microSD
™
card
• 8Mx32-bit SDRAM, 1Mx16bit SRAM and 8Mx16-bit NOR Flash
• 1 1-Gbit Twin Quad-SPI NOR Flash memory or two 512Mb Quad-SPI NOR Flash
memories
• Potentiometer
• 4 colored LEDs
• Reset, wakeup, tamper or key buttons
• Joystick with 4-direction control and selector
• Board connectors
–Power jack
– 3 USB with Micro-AB
– RS-232 communications
– Ethernet RJ45
– FD-CAN compliant connection
– Stereo headset jack including analog microphone input
– 2 audio jacks for external speakers
–microSD
™
card
– JTAG/SWD and ETM trace
• Board expansion connectors:
– Extension connectors and memory connectors for daughterboard or wire-wrap
board
• Flexible power-supply options: ST-LINK USB V
BUS
or external sources
• On-board ST-LINK/V2-1 debugger/programmer with USB
re-enumeration capability: mass storage, virtual COM port and debug port
• Comprehensive free software libraries and examples available with the STM32Cube
package
