Ball Pin Assignment

T4 PG3 ARDUINO_D8_GPIO

Y1 PE2 ETH_TXD3

U2 PA3 LTDC_B5

Y2 PC2 ETH_TXD2

V2 PG2 GPIO5_MCO2

AA1 PG14 ETH_TXD1

W1 PG1 HDMI_INT_GPIO

AA2 PG13 ETH_TXD0

U3 ANA0 ARDUINO_A0_ADC1_IN0

AB3 PA0 PA0_WKUP_PMIC_INT

U4 ANA1 ARDUINO_A1_ADC1_IN1

AA4 PA1 ETH_REF_CLK

V3 PA5 TypeC_Power_CC2_ADC1_IN19

V4 PA4 TypeC_Power_CC1_ADC1_IN18

AB1 PB11 ETH_TX_EN

AB2 PG4 ETH_GTX_CLK

AC3 PA2 ETH_MDIO

AA6 PC1 ETH_MDC

Y6 PG5 ETH_CLK125

AA3 PH3 LTDC_R1

AB6 PB0 ETH_RXD2

Y4 PF15 I2C1_SDA

AA7 PB1 ETH_RXD3

AC4 PF14 ARDUINO_A2_ADC2_IN6

Y5 PF13 ARDUINO_A3_ADC2_IN2

AB4 PH2 LTDC_R0

AB7 PC5 ETH_RXD1

AC7 PC4 ETH_RXD0

Y9 PF12 ARDUINO_A5_ADC1_IN6

Y10 PF11 SAI2_SD_B

AB8 PA7 ETH_RXDV

AC8 PA6 ETH_MDINT

AB5 PC0 LTDC_R5

Y3 PB10 GPIO14_USART3_TX

AC5 PB12 GPIO15_USART3_RX

AA10 PB13 GPIO16_USART3_CTS_NSS

Y8 PB5 ETH_ETH_CLK

Y7 PG11 STLK_UART4_TX

Y11 PH6 ARDUINO_D9_TIM12_CH1

AB10 PB8 LTDC_B6

AB9 PG8 GPIO17_USART3_RTS

UM2637

STM32MP157x-DKx I/O assignment

UM2637 - Rev 2

page 35/47
