8 STM32MP157x-DKx I/O assignment
Table 26. Discovery kit I/O assignment
Ball Pin Assignment
A2 PH5 BT_HOST_WAKE
C2 PH10 LTDC_R4
B2 PH12 LTDC_R6
D1 PH13 LTDC_G2
C3 PH14 LTDC_G3
B1 PH15 LTDC_G4
C1 PI0 LTDC_G5
E3 PI1 LTDC_G6
E2 PI2 LTDC_G7
E1 PI3 HDMI_I2S2_MOSI
E4 PI4 LTDC_B4
F3 PI5 SAI2_SCKA
F4 PI6 SAI2_SDA
F2 PI7 SAI2_FSA
G1 PZ1 BT_PCM_1_SDI
G4 PZ3 BT_PCM_1_WS
H4 PI9 LTDC_VSYNC
G3 PZ0 BT_PCM_1_CK
J4 PZ2 BT_PCM_1_SDO
G2 PZ4 PMIC_I2C4_SCL
K4 PG12 LTDC_B1
H2 PZ5 PMIC_I2C4_SDA
H1 PZ6 BT_REG_ON
J3 PZ7 BT_DEV_WAKE
D2 PD6 BT_USART2_RX
L3 PD14 ARDUINO_D3_TIM4_CH3
J2 PD15 ARDUINO_D5_TIM4_CH4
K3 PD8 LTDC_B7
K1 PD9 LTDC_B0
L4 PI8 LPO_32OUT2
K2 PC13 PC13_ANTI_TAMP_PMIC_WAKEUP
N2 PA13 LED1_GPIO
T2 PA14 LED2_GPIO
P4 PI11 PI11_STUSB1600_IRQN_WKUP5
T1 PI10 LTDC_HSYNC
W4 PH7 LED_Y_GPIO
U1 PF3 GPIO7_GPIO
W2 PC3 ARDUINO_A4_ADC1_IN13
UM2637
STM32MP157x-DKx I/O assignment
UM2637 - Rev 2
page 34/47
