ST STM32U083C-DK - Mikrobus Compatible Connectors (CN12 and CN13); Table 16. Description of the Mikrobus Connector Pins

7.3
mikroBUS
™
compatible connectors (CN12 and CN13)
The mikroBUS
™
compatible connectors CN12 and CN13 are a pair of 1×8-pin female connectors with a 2.54 mm
pitch. The mikroBUS
™
pinout assignment is available at the mikroe.com website.
Table 16 shows the definition of the pins.
Table 16. Description of the mikroBUS
™
connector pins
Pin name
mikroBUS
™
function
Pin number Pin number
mikroBUS
™
function
Pin name
PA0 AN 1 1 PWM PB3
PB10 RST 2 2 INT PB4
PA15 CS 3 3 RX PA3
PA5 SCK 4 4 TX PA2
PA6 MISO 5 5 SCL PB8
PA7 MOSI 6 6 SDA PB7
- +3.3 V 7 7 +5 V -
- GND 8 8 GND -
