Stanley K1200 User Manual

36
Figure 17 - Removing the top K1200
b) Next, you must fit the tabs of the casings into the slots in the pillars and in the rear grille of the equipment.
Figure 18 - Assembly of the casings K1200
The front tabs of the casings (3) must be fitted into the slots at the front of the unit (4). The rear tabs (5) fit into the slots on the
sides of the unit (6).
Figure 19 - Assembly of the casings K1200
It should then be moved downwards so that the casings stay fixed (7).
Figure 20 - Assembly of the casings K1200
2
3
4
5
6
7
2
