38
• Curved
Set of casings – chosen colour 10 Screws Din 7981 4,2x9,5
(CO0704132501019)
Figure 24 - Kit K2
13.2.1. Flat and Curved
a) To fit the upper front cover (A), it must be placed on the front of the unit and then two Din 7981 4.2x9.5 screws accessible
through the upper part of the unit (1) and another two screws in the lower part of the front cover (2) must be tightened.
Figure 25 - Fitting the front cover K1700 and K2300
b) Then, to assemble the side covers you must fit the bottom holes of the covers (3) in the guides found on the bottom of the
appliance (4).
Figure 26 - Assembly of the casings K1700 and K2300
1
2
3
4
A
