MDP Operation & Maintenance Manual | 11
overheating or damage to the hydraulic system.
• Cycle the cylinder completely when processing.
Fully cycling will allow hydraulic uid to circulate and
prevents overheating.
• When working in conned spaces, keep watch on
exposed parts to avoid damage.
• Avoid collision of the boom or jaws, especially when
working with limited visibility or inside buildings.
Know the height and reach of the attachment during
operation, transport and when swinging the excavator.
Watch out for overhead obstacles.
• DO NOT alter factory preset hydraulics. This may void
the warranty.
• DO NOT use attachment as a jack hammer or
wrecking ball.
• DO NOT operate a poorly maintained or damaged
attachment.
• The attachment is not a dozer. DO NOT position it on
the ground and travel forward.
• Lifting lugs are to be used for shipping and installation.
Do not use them in cable-hung applications.
TECHNICAL SPECIFICATIONS
Model Jaw Type Weight Jaw Opening Jaw Depth Reach
Minimum Excavator
Size
MDP 20R
Cracker
4,600 Lbs.
(2,100 Kg)
25 Inches
(640 mm)
27 Inches
(690 mm)
9.8 Feet
(3 m)
40,000 Lbs.
(18 M/Ton)
Pulverizer
5,250 Lbs.
(2,400 Kg)
25 Inches
(640 mm)
27 Inches
(690 mm)
9.8 Feet
(3 m)
40,000 Lbs.
(18 M/Ton)
MDP 27R
Cracker
6,300 Lbs.
(2,900 Kg)
32 Inches
(810 mm)
31 Inches
760 mm)
9.6 Feet
(2.9 m)
55,000 Lbs.
(25 M/Ton)
Pulverizer
6,950 Lbs.
(3,200 Kg)
28 Inches
(710 mm)
30 Inches
(760 mm)
9.6 Feet
(2.9 m)
55,000 Lbs.
(25 M/Ton)
MDP 35R
Cracker
8,250 Lbs.
(3,700 Kg)
38 Inches
(970 mm)
36 Inches
(910 mm)
11.3 Feet
(3.4 m)
70,000 Lbs.
(32 M/Ton)
Pulverizer
9,000 Lbs.
(4,100 Kg)
34 Inches
(860 mm)
36 Inches
(910 mm)
11.3 Feet
(3.4 m)
70,000 Lbs.
(32 M/Ton)
MDP 50R
Cracker
12,400 Lbs.
(5,600 Kg)
50 Inches
(1270 mm)
45 Inches
(1140 mm)
13.1 Feet
(4 m)
99,000 Lbs.
(45 M/Ton)
Pulverizer
13,900 Lbs.
(6,300 Kg)
50 Inches
(1270 mm)
45 Inches
(1140 mm)
13.1 Feet
(4 m)
99,000 Lbs.
(45 M/Ton)
MDP 90 Pulverizer
2,100 Lbs.
(9,500 Kg)
56 Inches
(1420 mm)
49 Inches
(1240 mm)
15.2 Feet
(4.6 m)
187,000 Lbs.
(85 M/Ton)
THIRD MEMBER CONTROLS
Learn the control for each movement of the
attachment before attempting to operate.
