REMOVING MDP FROM THE EXCAVATOR
1. Curl the attachment under the boom of the excavator and use blocking to support the stick cylinder.
2. Insert the Transport Pin.
Disassembly of any pin-connected attachment can be
hazardous. Never remove any pins unless MDP is on the
ground and blocked up. Serious injury could result.
3. Remove the stick cylinder pin from the MDP.
Trapped hydraulic pressure may be present after the base
removing hydraulic hoses or injury or death could result.
4. Carefully remove the jump-lines at the MDP hydraulic connectors.
Note: Plug hydraulic hoses to prevent contamination.
5. Unpin the boom pivot pin and release the weight of MDP.
STORING MDP
1. Securely block the attachment o the ground using wood blocking.
2. Plug all open hydraulic ports.
3. Grease MDP as described in “Lubrication” on page 17.
