Stanley MC521 Pro User Manual

MC521 PRO Control Box
03.23.2017
1.800.7.ACCESS • www.stanleyaccess.com • Document # 204090 REV D 47
Copyright 2017 Stanley Access Technologies, LLC. All rights reserved. Reproduction
in whole or in part without the express written permission of Stanley is prohibited.
Values shown as grayed out do not aect moon of the door and may need to be adjusted to suit the applicaon
Attachment 10
Table 1 Recommended Values for Concealed Doors - Motor 1
Index Description Light Weight Door (100lbs) Heavy Weight Doors (350lbs)
Single Pair Single Pair
Low
Energy
Full
Energy
Low
Energy
Full
Energy
Low
Energy
Full
Energy
Low
Energy
Full
Energy
00 Open speed, revoluons per second 09 35 09 35 06 25 06 25
01 Check speed, revoluons per second 04 07 05 07 05 04 05 5
02 Stall speed, percent of PWM counts See Aachment 11
03 Open check 20 40 20 35 25 45 25 45
04 Magic Touch sensivity 00 00 00 00 00 00 00 00
05 Magic Touch hold open me HH=55
KP=22
HH=40
KP=16
HH=55
KP=22
HH=40
KP=16
HH=55
KP=22
HH=40
KP=16
HH=55
KP=22
HH=40
KP=16
06 Hold-open delay HH=55
KP=22
HH=15
KP=06
HH=55
KP=22
HH=15
KP=06
HH=55
KP=22
HH=15
KP=06
HH=55
KP=22
HH=15
KP=06
07 Open torque, percent of full torque 25 75 25 75 25 75 25 75
08 Check torque, percent of full torque 25 40 25 40 25 75 25 75
09 Stall torque, percent of full torque 25 25 25 25 25 25 25 25
10 Open Check Boost 09 10 09 12 09 12 9 14
11 Safety Logic 00 00 00 00 00 00 00 00
12 2S Operaon 00 00 00 00 00 00 00 00
13 Obstrucon Time HH=50
KP=20
HH=50
KP=20
HH=50
KP=20
HH=50
KP=20
HH=50
KP=20
HH=50
KP=20
HH=50
KP=20
HH=50
KP=20
14 Open Acceleraon Slope 60 60 60 60 60 60 60 60
15 Open Braking Slope 35 20 20 20 35 35 35 35
16 Delay of door moon. Motor 1 00 00 00 00 00 00 00 00
17 No Reverse on Obstrucon 00 NA 00 NA 00 NA 00 NA
18 Lock Delay 00 00 00 00 00 00 00 00
19 Manual Mode sensor override 00 00 00 00 00 00 00 00
31 O Mode 00 00 00 00 00 00 00 00
32 Lock Logic 01 01 01 01 01 01 01 01
37 Unlock Time 10 10 10 10 10 10 10 10
HH = Hand Held
KP = Key Pad
