Stanley MC521 Pro User Manual

MC521 PRO Control Box
14 Document # 204090 REV D • www.stanleyaccess.com • 1.800.7.ACCESS
Copyright 2017, Stanley Access Technologies, LLC. All rights reserved. Reproduction
in whole or in part without the express written permission of Stanley is prohibited.
03.23.2017
Table 1. FIS Procedure Using Pushbuttons
Step Description
Display
Index Value
Status
Code
1 Set Funcon switch to “Closed”
2 Turn power on.
3 Unlock keypad. 99 00 00
4 Restart FIS 96 01 A0
5 Select door type (Refer to Table 2) 00
Refer to Table 2
A0
6 Select Motor 1 handing 01
00 = Right hand
01 = Le hand
A0
7 Select Motor 2 handing 02
00 = Right hand
01 = Le hand
A0
8 Accept FIS. 03 01 A1
9 Make changes: Safety Logic
(Note: If there are no sensors connected,
leave at value of 00.)
ABBREVIATIONS:
DM - Door Mounted Sensors
OHP - Overhead Presence Sensor
ACT - Acvaon Side Presence Sensor
STL - Stall Presence Sensor
SAF - Safety Presence Sensor
11 Safety Logic. INDEX 11 - 00 to 15
00 = Sensor
01 = Sentrex
02 = Carpet
03 = Carpet 12 Sec.
04 = Non-Monitored Bi-Fold
05 = Monitored DM & OHP. ACT, STL
& SAF, both single & pair
06 = Monitored DM & OHP Dual
Egress. STL, ACT, STL & SAF
07 = Monitored OHP & Photobeam.
SAF & Photobeam
08 = Monitored DM ACT. ACT both
single & pair
09 = Monitored OHP Bi-Fold. SAF
10 = Monitored DM. ACT & STL both
single & pair
11 = Two OHP Monitored Bi-fold. SAF,
Bi-Fold/Swing
12 = Monitored Hub Based Sensors.
ACT & STL
13 = Swing-Guard T
14 = Monitored DM Stall & OHP both
single and pair. STL & SAF
15 = Monitored DM Stall & OHP Dual
Egress. STL & SAF
A1
10 Function Switch: Switch to OPEN,
momentarily, then CLOSED/LOCKED.
Wait for learn sequence to end.
Display will show A2 when finished.
A2
11 Lock Keypad 99 01 00
12 Final Tune in
