MC521 PRO Control Box
10.21.2015
1.800.7.ACCESS • www.stanleyaccesstechnologies.com • Document # 204066 REV D2 9
Copyright 2015, Stanley Security Solutions. All rights reserved. Reproduction in whole
or in part without the express written permission of Stanley is prohibited.
Table 1. FIS Procedure using Pushbuttons
Step Description Display
Index Value Status Code
1 Set Funcon switch to Closed.
2 Turn power on.
3 Unlock keypad. 99 00 00
4 Restart FIS. 96 01 A0
5 Select door type: Slide, 01 single motor or 02 dual motor. 00 01 (single)
02 (dual)
6 Select handing: 00 Right or 01 Le.
Manually open door and note rotation of belt pulleys.
If counterclockwise (CCW) use right hand during FIS.
If clockwise (CW) use left hand during FIS.
01 00 (right)
01 (le)
A0
7 Accept FIS. Display will go to A1. 03 01 A1
8 Make changes: Funcon switch
01 Rocker or 00 Rotary. The INDEX will start at 00.
11 01 (Rocker)
00 (Rotary)
A1
9 Select Lock Logic: Lock Logic, 00 = Fail Safe; 01 = Fail Secure.
NOTE: For locks with circuit board, set to 01 Fail Secure. For
locks with no circuit board, set to Fail Safe or Fail Secure.
07 00 (Fail Safe)
01 (Fail Secure)
10
WARNING: During this sequence the sensors are inactive and the
door has NO SAFETY. To stop the door, TURN POWER OFF or PUT
THE DOOR INTO BREAKOUT.
Function switch: Switch to OPEN, momentarily, then CLOSED/
LOCKED. Wait for the learn sequence to end.
Display will show A2 when nished.
A2
11 Lock keypad. 99 01 00
12 Final Tune in.
Table 2. Index List
Index Description
00-89 Sengs Values, see Table 3.
90-95 Reserved.
96 Command – Restart FIS. Entering “01” will cause FIS to restart.
97 Firmware – Entering “01” will display “FE” followed by two pairs of digits followed by “FE”. For example,
if the rmware was 0609 the controller will display “FE” “06” “09” “FE”.
98 Command – Restart auto conguraon. Entering “01” will cause auto conguraon.
99 Command – Lock. Entering “01” will lock all value inputs except this index. This prevents inadvertent
changes to input values. Values may be unlocked by entering “00” in this index.
Index 98 sets the Control Box to A1” keeping all previous values and then relearns the encoder count.
