Basic Operation
UR44 Operation Manual 26
7. Set the Channel Strip settings and REV-X
settings on the Input Settings window.
Select the Channel Strip Insertion location
depending on the desired insert point. The default
setting is “Lower” (applied to both the monitor signal
and the recording signal). For details on the Insertion
location, refer to the “Effect Insertion location”
(
page 16 ) in the section “Dedicated Windows for
Cubase Series.”
8. Click [I] to start the recording.
9. After finishing the recording, click [ J ] to stop
it.
10. Turn [Monitor] off (dark) for the just-
recorded audio track.
11. Click the Ruler to move the project cursor to
the desired point for starting playback.
12. Click [ R ] to check the recorded sound.
When listening to the sound over monitor speakers,
adjust the output signal level by the [OUTPUT
LEVEL] knob on the device.
For more detailed instructions on using Cubase
series programs, refer to the PDF manual, available
from [Help] in the Cubase series menu.
Programs Other Than Cubase Series
1. Launch your DAW software.
2. Open dspMixFx UR44.
For instructions on how to open dspMixFx UR44,
refer to the section “How to Open the Window”
(page 10).
3. Adjust the input signal level of the
microphone with the [INPUT GAIN] knob on
the device.
To achieve optimum recording levels, increase the
input level with the [INPUT GAIN] knob until the
[PEAK] indicator lights in red, then slowly bring the
level down until the indicator lights slightly when the
input level is maximum.
4. Adjust the output signal level of the
headphone with the [PHONES] knob on the
device.
5. Set the Channel Strip settings and REV-X
settings on dspMixFx UR44.
6. Start recording on your DAW software.
7. After finishing recording, stop it.
8. Playback the newly recorded sound to
check it.
For more detailed instructions on using the DAW
software, refer to your particular DAW’s software
manual.
