stellar labs 23000 - Mast Assembly - PN 100730 Parts List

Stellar
®
23000 Articulating Crane Owner’s Manual | Page 31
PN 100730
ITEM PART DESCRIPTION QTY
1 100731 MAST 23000 V3 1
2 101532 CYLINDER ASM 23000 V3 MAST 1
3 0635 BUSHING 40DXR32 GARLOCK 2
4 2227 BUSHING BPC48DXR48 3.00X3.00 2
5 16344CR PIN 2.50X16.25 D&T ZC 1
6 41053 PIN 3.00X17.50 D&T SS 1
7 13315 PIN CAP 0.56X4.00X0.19 YZ 4
8 11297 PLATE INSPECTION MAST 23000 1
9 D0790 WASHER 0.50 SAE FLAT YELLOW GR8 4
10 10172 CAP SCR 0.50-13X1.00 HHGR8 4
11 18041 WASHER 0.88 SAE FLAT YELLOW GR9 18
12 42308 CAP SCR 0.88-9X2.75 HHGR9 16
13 17962 CAP SCR 0.88-9X4.50 HHGR9 2
14 0343 WASHER 0.31 USS FLAT 2
15 0522 WASHER 0.31 LOCK 2
16 0484 CAP SCR 0.31-18X0.50 HHGR5 2
Mast Assembly - PN 100730 Parts List
