Page 40 | Stellar
®
23000 Articulating Crane Owner’s Manual
GREASE FITTINGS SHOWN FOR REFERENCE
4
9
1
6
4
5
3
2
CYLINDER SEAL KIT 105545
7
C-BALANCE VALVE C1090
BUSHINGS INCLUDED IN 128718
BUSHING PART NUMBER 0635
NUMBER LOCATION
8
NOTES:
CYLINDER SERIAL
10
Extension Cylinder Assembly- PN 128719
