stellar labs 23000 - Model 23000 Specifications

Page 2 | Stellar
®
23000 Articulating Crane Owner’s Manual
Crane Rating: 230,000 ft-lbs ( 31.8 ton meters)
Standard Boom Length: 13’ 4” (4.06m) from CL of Crane
Boom Extension: Hydraulic 37” (0.94 m)
Maximum Horizontal Reach: 16’ 5” (5.0 m) from CL of Crane
Maximum Vertical Lift:
20’ 8” (6.29m)
(From Base)
Cylinder Specications: Inner Lift Cylinder: 8” (20.3 cm) bore with integral pilot
operated counterbalance valves
Outer Lift Cylinder: 6.5” (16.5 cm) bore with integral pilot
operated counterbalance valves
Extension Cylinder: 5” (12.7 cm) bore with integral pilot
operated counterbalance valves
Rotation: 315 degree power
(planetary gear with pinion)
Lifting Capacities: 14,000 lbs @ 16’5” (6350 kg @ 5.m)
Power Supply Required: PTO & Pump - 16 gpm @ 4,400 psi
(60 lpm @ 304 bar)
Controls: Fully Proportional Paddle Controls for all functions.
Stowed Height:
116” (295 cm)
(Above Truck Frame)
Mounting Space Required: 48” (121.9 cm)
Chassis RBM (Recommended): 2,760,000 in-lb
Approximate Shipping Weight: 11,500 lbs (5,220 kg)
Model 23000 Specications
