Stellar
®
23000 Articulating Crane Owner’s Manual | Page 37
PN 61245
ITEM PART DESCRIPTION QTY
1 61244 CYLINDER 6.50X35.69 1
2 15995 MANIFOLD ASM DUAL T2A 5000PSI 1
3 1554 FTG 8-8 MFS-MORB STRAIGHT 2
4 C2252 FTG 8-10 MFS-MORB STRAIGHT 2
5 41496 TUBE ASM 0.50X14.16 23000 YZ 2
6 18701 CLAMP PORT TUBE ZR518 2
7 19370 HOSE CLAMP 5.63-8.50 5416K39 2
8 104021 FTG 2-2 MP-FP 45 GREASE LINE 1
9 104019 FTG 4-2 PTC-MP STRAIGHT GREASE LINE 1
10 104020 FTG 4-2 PTC-MP 90 GREASE LINE 1
Outer Cylinder Assembly - PN 61245 Parts List
