23000 Articulating Crane Owner’s Manual | Page 52
Replacement Parts
ASSEMBLY COMPONENTS
PART NO. DESCRIPTION
0635 BUSHING 2.50” X 2.00”
0865 BUSHING 3.00” X 2.00”
2227 BUSHING 3.00” X 3.00”
4381 BUSHING 2.00” X 2.00”
5739 BUSHING 2.50” X 3.00”
8819 BUSHING 2.00” X 1.00”
13343 BUSHING 2.50” X 1.00”
13817 BUSHING 2.50” X 1.50”
17320 BUSHING 2.50” X 2.50”
25574 BUSHING 2.50” X 1.75”
8377 PIN CAP 0.56 X 3.50” X .25 SS
8455 PIN CAP 0.69 X 3.50” X .25 SS
9142 PIN CAP 0.56 X 2.50” X .25 SS
13315 PIN CAP 0.56 X 4.00” X .25 SS
10172 CAP SCREW 0.50-13 X 1.00 GR 8
D0790 WASHER 0.50 FLAT GR 8
2257 SNAP RING 2.00” INTERNAL
C5644 GREASE ZERK 1/8 NPT 45 DEGREE (GREASE LINE KIT OPTION)
C1592 GREASE ZERK 1/8 NPT (CYLINDERS / PIVOT POINTS)
40455 WEAR PAD 2.00” X 8.00” X 1.50”
41059 WEAR PAD 3.00” X 4.00” X 1.75”
41060 WEAR PAD 3.00” X 4.00” X 1.38”
41058 WEAR PAD 1.00” X 4.00” X 6.00”
69277 SAFETY LATCH - 15 TON HOOK CROSBY SWIVEL HOOK
ELECTRICAL COMPONENTS
PART NO. DESCRIPTION
89155 12V CHARGER FOR SCANRECO RADIO SYSTEM
89154 BATTERY FOR SCANRECO RADIO SYSTEM
89639 BELT - TRANSMITTER HARNESS (WAIST)
92549 FAN 16.00 PUSH 12 V (HYDRAULIC RESERVOIR)
6394 TOGGLE SWITCH (OUTRIGGER OPERATION)
8623 TOGGLE SWITCH (OUTRIGGER OPERATION)
C4815 TOGGLE SWITCH (OUTRIGGER OPERATION)
54393 TEMPERATURE SWITCH (HYDRAULIC RESERVOIR)
22921 E-STOP SWITCH (CRANE PANIC BAR)
61562 CONTACT SWITCH (PANIC BAR) SWITCH INSIDE E-STOP HOUSING (22921)
D0045 OVERLOAD ALARM
COMPRESSOR COMPONENTS (SHD245 OPTIONAL)
PART NO. DESCRIPTION
3853 PILOT VALVE 145/175 PSI (SHD245 CPRSR)
C4913 SOLENOID VALVE (SHD245 CPRSR)
C4914 PRESSURE RELIEF VALVE (SHD245 CPRSR)
C0864 HOBBS AIR PRESSURE SWITCH (SHD245 CPRSR)
