Operation
Hydraulic Hook Height Adjustment - Raise
With the hooklift in the stowed position
without a body, put the truck in neutral
and engage the PTO.
Hydraulic Hook Height Adjustment - Lower
Pull the control lever labeled ‘hook’
to raise the hook height. When
raised completely, release the lever
and disengage the PTO.
With the hooklift in the stowed position
without a body, put the truck in neutral
and engage the PTO.
Push the control lever labeled ‘hook’
to lower the hook height. When low-
ered completely, release the lever
and disengage the PTO.
Fully extend
hook height.
Fully retract
hook height.
