stellar labs Slider26 - Main Cylinder Assembly - PN 53770

 Slider26 Owner’s Manual
1
2
2
8
6
3
9
5
4
7
3
10
11
12
13
PN 53770
ITEM PART DESCRIPTION QTY.
1 53447 CYLINDER 5.00X78.00 2
2 1554 FTG ADAPT 8-F5OLO-S 6
3 37179 FTG ST RUN TEE 8-10-8R5OLO 2
4 C2376 FTG ADAPT 8-C6LO-S 1
5 53773 TUBE ASM 0.50 SLIDER 26 CS EXTEND YZ 1
6 53849 TUBE ASM 0.50 SLIDER 26 CS RETRACT YZ 1
7
53847 TUBE ASM 0.50 SLIDER 26 SS EXTEND YZ 1
8
53848 TUBE ASM 0.50 SLIDER 26 SS RETRACT YZ 1
9 15995 MANIFOLD ASM DUAL T2A 5000PSI 1
10 18701 CLAMP PORT TUBE ZR518 5
11 19369 HOSE CLAMP 4.13-7.00 5416K38 5
Main Cylinder Assembly - PN 53770
