A100K11311
Pulse Technical Manual
1 Introduction
This document describes the conguration of the Pulse System using:
- STENTOFON IP intercom stations
- STENTOFON IP speakers
- 3
rd
-party IP telephones
- IP telephone gateways
- STENTOFON IP DECT 300
1.1 Pulse System Overview
STENTOFON Pulse is an IP-based intercom system for upto 16
intercom stations. The system works with all STENTOFON IP intercom
stations. In addition, it is possible to extend the system with up to 10
3
rd
-party SIP terminals and 4 SIP gateways. One of the STENTOFON
IP intercom stations is designated as the Pulse Server, which acts as
a SIP server, managing how calls are set up and routed, and also is the
single point for conguration of all intercom stations in the system.
L All IP intercom stations in a Pulse installation must be located on
the same LAN (IP subnet).
1.2 Pulse SIP Licenses
The SIP station license allows you to extend your system with IP
telephones, IP DECT cordless phones, and PC and mobile VoIP clients.
The SIP trunking license allows you to connect to other telephone
systems using SIP trunks or analog and mobile network gateways.
License Item Number
Pulse SIP Station License - 1 user 1009643111
Pulse SIP Station License - 4 users 1009643112
Pulse SIP Trunking License 1009643121
PoE Network Switch
Turbine IP Station
Directory Number: 14
Name: Elevator
IP Address: 169.254.1.104
or DHCP
Turbine IP
or DHCP
Station
Directory Number: 13
Name: Entrance
IP Address: 169.254.1.103
IP Master Station - Pulse Server
Directory Number: 10
Name: Reception Desk
IP Address: 169.254.1.99
