Sterlco M2B - Sample Ramp Soak Program

17
Sample Ramp Soak Program
Segment Prompt Function Time (Min.) Setpoint
o
F
1TI 1st Event 1
1SP 50
2TI 2nd Event 2
2SP 150
3TI 3rd Event 2
3SP 150
4TI 4th Event 2
4SP 100
5TI 5th Event 1
5SP 100
6TI 6th Event 2
6SP 50
7TI Un-Used 0
7SP Hold Last Setpoint 50
↓
Un-Used
GTI Un-Used 0
GSP 50
END Stay at present set pt. (gSP) HLd
END Turn off outputs at end of program Oof
END Repeat program at 1TI Lop
