Appendix A
Hard Keys
Home (Index Keys)
Set Point Process Heat Low
Heat
High
SP1 ### Main Set Pt. 175 175
ALO ### Alarm Low -100
AHI ### Alarm High 200
Set Point Process Heat Low
Heat
High
SYS On/OFF System On or Off (Standby) On
Prg run/HLd note 1 Programmer Run/Hold
ti ### note 3 Program Segment Time remaining
#ti ### note 3 Program Segment Time
#SP ### note 3 Program Segment Set Point
tun Tune choice PID PID
SLF Self Tuning
Lrn YES/No Start Learn
dFa OFF, 1 to 7
Damping factor 1=less, 7 = more
ratio rate to reset
33
Pid Manual PID tuning
PbH 1 to 5000 Proportional Band 1 (deg or counts) 14 14
PbC 1 to 5000 Proportional Band 2 (deg or counts) 20 10
rES 0 to 999.9 Reset time in sec 1.5 1.5
OFS 0 to 99.9 Manual reset value in percent OFF OFF
rtE 0 to 99.99 Rate time in minutes 0.05 0.05
SLO Slow response process
nor Normal response process
FAS Fast response process
FPC 0 to 100
Fuzzy intensity in percent 0 = off
Impact fuzzy logic has on process
50 50
Fbd 1 to 400 Fuzzy Band in deg. or counts = to PBH 14 14
FrC 0 to 99.9
Fuzzy rate of change in deg. or counts per
second
2.5 2.5
PEA ### Peak PV, ENTER to reset to present PV
UAL ### Valley PV, ENTER to reset to present PV
2SP ### Auxiliary Set Pt. 0 0
tc ### Note 4 T/C Monitor Temp
FAL 0 to 100 Note 4 Flow Alarm Low 0 0
FAH 0 to 100 Note 4 Flow Alarm High 100 100
AUt OFF, 1 to 5 Auto vent cycle OFF, 1 to 5 min. 1.0 OFF
HiH On/OFF/AUt High Heat On/ Off/Auto AUt AUt
