Sterlco M2B - Secondary Menu (Up and Enter Keys)

34
Secondary Menu (Up and Enter Keys)
* manual reset by simultaneously pressing index & down keys for 5 seconds.
Set Point Process Heat Low
Heat
High
Unt F/C Degrees F or C F F
AL1 OFF/Lo/Hi/HL/Eut Alarm (Off, Low, High, Hi.Lo, Event) OFF OFF
A1t AbS/dE Absolute or Deviation to SP1 dE dE
A1r OnF/HOL * Alarm Reset, auto reset/manual reset OnF OnF
A1i On/Off Power Interrupt OFF OFF
A1H On/OFF
Power inhibit, suspend alarm until PV enters
non-alarm condition
On On
A1S CLS/OPE Contact Closed/Open @ Alarm CLS CLS
A1L O on/oFF Lamp (on/off) contact closed Oon Oon
A1b On/OFF Alarm on Loop Break OFF OFF
Prg On/OFF Programmer ON/OFF (ramp/soak) OFF OFF
SEt On/OFF
Prog, values available for viewing &
changing
OFF OFF
StA On/OFF note 2 Status of Prog. in Home Position OFF OFF
SEC 1 S/6OS note 2 Prog. time base (1 or 60 sec.) 1-S 1-S
#ti 0 to 9999 note 2 Segment time 0 0
#SP #### note 2 Segment Set Pt. 0 0
#A1 On/OFF note 2 Alarm 1 Event OFF OFF
#A2 On/OFF note 2 Alarm 2 Event OFF OFF
End Hld/Oof/LoP/SPt note 2 Programmer End (Hold, Off, Loop, SP) OFF OFF
A2L ### Alarm 2 Low
A2H ### Alarm 2 High
Ato On/OFF Auto/Man OFF OFF
rUP On/OFF Anti-Reset windup OFF OFF
Pct On/OFF Percent Output in SV display OFF OFF
LPb OFF, 1 to 9999 Loop Break time in sec. OFF OFF
POL ### Process Output Low 0 0
POH ### Process Output High 250 550
POS InP/SP1 Process Output Source InP InP
rSL ###
4 mA = -62.5
0 mA = 0
20 mA = 250
Remote Set Pt. Low 0 0
rSH ### 250 Remote Set Pt High 250 550
rSP On/OFF Remote Set Pt On/OFF OFF OFF
L-r LOC/rE Comm Local/ Remote LOC LOC
Add 1 to 3FF Comm Address Viewable Only 32 32
