36
Note 1: Only present when Pro = On
Note 2: Only present when SEt = On
Note 3: Only present when StA = On
Note 4: Only present when the option is active
Set Point Process
Water
Temp.
Control
Unit
Heat Low
Oil Temp.
Control
Unit
Heat
High
S1C O on/off Lamp (on/off) contact closed Oon Oon
S2t AbS/dE Absolute of Deviation to SP1 dE dE
S2S dir/rE Direct or Reverse Acting dir dir
S2L 0 to 90 Output 1 low limit 0 0
S2H 10 to 102 Output 1 high limit 100 100
S2C O on/oFF Lamp (on/off) contact closed Oon Oon
AL2 OFF/Lo/Hi/HL/Eut Alarm (Off. Low, High, Hi/Lo, Event) OFF OFF
A2t AbS/dE Absolute or Deviation to SP1 dE dE
A2r OnF/HOL Alarm Reset (On/Off, Hold) OnF OnF
A2i On/OFF Power Interrupt OFF OFF
A2H On/OFF Power Inhibit On On
A2S CLS/OPE Contact Closed/Open @ Alarm CLS CLS
A2C O on/oFF Lamp (on/off) contact closed Oon Oon
A2b On/OFF Alarm on Loop Break OFF OFF
Add 1 to 3FF Note 4 Comm Address Hexadecimal (992/3) 32 32
nAt OFF, 1 to 99 Note 4 No activity Timer Minutes OFF OFF
Bau 300-19.2 K Note 4 Comm baud rate 9.6 9.6
