Compact control panel 4A, 4A/M und 8A, 8A/M
Description of operating
Extraction limit (by operating time)
To activate see notes on page 68, switch DIP-Switch 6 to ON.
Teaching
Close the windows! Press the switches “open” and “closed” (STOP) at the vent switch as long as the display “open” is
ashingfast.Openthemotorwiththeswitch“open”uptothepositionrequiredwithinthenext10sec.andstopthemotor
in this position by releasing the switch “open”. If no other switch is pressed within the next 10 sec. the learning phase is
nished.
To deactivate
See note on page 68, switch DIP-Switch 6 to OFF.
Note: in case of mains or battery failure or SHE activation the function is out of order. In case of mains or
battery failure, the windows close immediately.
LED display
In the SHE control panel and SHE manual call points.
The green LED display
OK
- operating OK - is shining. It goes out in case of:
• mains or battery failure
• malfunction of the line monitoring of the connected drives, automatic detectors or SHE manual call points.
The yellow LED display
-malfunction-isashingincaseof:malfunction,cableconnectiondefective,mainsand/or
battery failure.
Caution: If any malfunction is indicated the malfunction has to be eleminated immediately. The perfect function
of the system is not longer guaranteed.
The red LED display - SHE activation - is shining in case of: manual or automatic SHE activation.
Closing with wind/rain detector
If a wind/rain detector or a rain sensor is connected, the windows close automatically in case of beginning winds and/or
rainfall,“VentilationOpen”displayashes,ventswitchoutoforder,thewindowscloseimmediatelyincaseofpoweror
battery failure.
Note: The ventilation function is out of order or locked in case of power or battery failure or SHE activation in
order to save battery power.
Master - Slave function
(Rev019 hardware version, software version V020001, see marking on the board)
The connection of several smoke control panels (master - slave function) allows a decentralized structure
with the advantage that the panels can be mounted as an energy source in the vicinity of the drives.
This cable cross sections can be due to the shorter lines to the actuators
decrease (see wire size chart).
A SHE trip only from the master control center via connected RWA switch or smoke detectors
and place will be forwarded to other connected slave stations.
It thus may be possible one SHE group.
