WORKSHOP MANUAL
1 - INTRODUCTION
EDITION
PAGE
4 /37
They are used to draw the attention of the operator, reminding him to perform the interventions
with the necessary attention and caution.
Indicates operations that should be carried out with utmost care to avoid impairing the func-
tionality and safety of the machine.
Indicates operations that should be carried out with utmost care to avoid injury to operators.
Highlights all those operations that require different working methods depending on the type
of machine, subsequent modifications and the accessories fitted.
Indicates cross-reference to other parts of the manual, followed by the number of the relevant
chapter, paragraph or sub-paragraph.
Some paragraphs are preceded by a definition that highlights their importance:
General reference for the correct maintenance execution and methods.
Specific procedures or information necessary to avoid damage to the machine or
equipment.
Non-observance will result in the risk of injury to oneself or others.
Non-observance will result in the risk of serious injury or death to oneself or
others.
Whenever reference is made to a position on the machine “front”, “back”,
“left” or “right” side, this refers to the positions of the seated operator.
The following abbreviations are used in this manual
Rh / Lh = Right / Left
Min / Max = Minimum / Maximum
Chap. = Chapter
Par. = Paragraph
PTO = Power Take Off
The terms “Cutting deck” or “Equipment” refer to the cutting-means assembly, connected to the
machine PTO by means of a belt.
