• Adhere strictly to local regulations governing the
disposal of cuttings.
• When the machine is withdrawn from service,
do not dump it in the environment, but take it to
a waste disposal facility in accordance with the
local regulations in force.
4 INSURING YOUR LAWNMOWER
Check the insurance on your lawnmower.
Contact your insurance company.
You ought to have fully comprehensive insurance
for trac, re, damage and theft.
5 ASSEMBLY
The battery must be fully charged befo-
Do not use the machine until all the in-
dications provided in the “ASSEMBLY”
section have been carried out.
Unpacking and completing the assem-
surface, with enough space for machi-
ne handling and its packaging, always
making use of suitable equipment.
5.1 ASSEMBLY COMPONENTS (3)
The machine is delivered with the seat, armrests,
steering wheel, tow bar, quick-t supports
dismantled. The battery is in its housing but not
connected.
The packaging holds the components needed for
assembly (3) as listed in the table below:
Pos. No. Description Dimensions
Contents of the bag
A 1 Tow bar /
B 2 Flanged screw 8 x 20
C 2 Screw for battery /
D 2 Nut for battery /
E 6 Washer 8,4 x 24 x 2,0
F 2 Shoulder washer /
G 4 Screw 8 x 20
H 2 Screw knob /
I 2 Ignition key /
J 1 Pin 6 x 36
K 1 Shim 16 x 38 x0,5
L 1 Shim 16 x 38 x 1,0
P 2 Screw M10 x 35
Q 2 Nut M10
R 2 Split lock washer 14 x 8,2 x 2
Installed on the front semi-axles
M 2 Safety rings /
N 2 Washer with internal wing /
Attached to the tool lift
O 2 Deck mount /
5.2 BONNET(5:A)
Open the bonnet to access the fuel cock,
battery and engine.
The bonnet can be opened as follows:
[Gear]
1. Set the lever (12:A; 12:B) to the forward
position.
[Hydrostatic]
1. Set the lever (13:A) to the forward position.
2. Lift the seat stopper (7:S) and fold the seat
forward.
3. Open the bonnet: take hold of the edge (5:A)
and lift.
4. Perform the above operations in reverse or-
der to close the bonnet.
It is strictly prohibited to start the engi-
ne when the bonnet is open.
5.3 BATTERY
For the type of battery installed on the machine,
please refer to “0 TECHNICAL DATA TABLE”
CAUTION! Battery acid is corrosive and
contact with it is harmful.
Handle the battery with care taking care
not to let acid leak out.
5.3.1 Battery connection (6)
Connect the battery to the machine’s electrical sy-
stem using the relative screws and nuts (6:F; 6:E):
1. Connect the red cable to the battery's posi-
tive terminal (+).
2. Connect the black cable to the battery’s ne-
gative terminal (-).
If the leads are disconnected/con-
nected in the wrong order, there is a
risk of a short-circuit and damage to the
battery.
Inverting the cable connections will da-
mage the alternator and the battery.
EN
ENGLISH
(Translation of the Original Instructions)
11
