Page #54 background imageLoading...
Page #54 background image
•
Fit thrust plate with bent corners
pointing towards gear housing.
•
Fit conrod with marking upwards.
- Fit gear wheel with bevelled side
of teeth pointing towards conrod.
392RA203
VA
392RA196
VA
54
