Stihl FR 460 TC-M User Manual

FR 460 TC-M
English
43
Engine
STIHL single cylinder two-stroke engine
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Weight
Overall length
Features
Noise and Vibration Data
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib.
Sound pressure level L
p
to ISO 22868
Sound power level L
w
to ISO 22868
Vibration measurement a
hv,eq
to
ISO 22867
The K-factor in accordance with
Directive 2006/42/EC is 2.5 dB(A) for
the sound pressure level and sound
power level; the K-factor in accordance
with Directive 2006/42/EC is 2.0 m/s
2
for the vibration measurement.
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
see www.stihl.com/reach.
Specifications
Displacement: 45.6 cc
Bore: 44 mm
Stroke: 30 mm
Engine power to
ISO 8893:
2.2 kW (3.0 bhp)
at 9,500 rpm
Idle speed: 2,700 rpm
Cut-off speed
(rated): 10,500 rpm
Max. output shaft
speed (cutting
attachment): 7,930 rpm
Spark plug (resistor
type):
NGK CMR 6 H,
Bosch USR 4 AC
Electrode gap: 0.5 mm
Fuel tank capacity: 750 cc (0.75 l)
Dry, without cutting
attachment and deflector 11.4 kg
without cutting
attachment 2800 mm
T Split boom (drive tube)
C Convenience feature
E ErgoStart
F Electric starter
M M-Tronic
with mowing head 100 dB(A)
with metal mowing
attachment 99 dB(A)
with mowing head 112 dB(A)
with metal mowing
attachment 112 dB(A)
Handle,
left
Handle,
right
with mowing
head 3.6 m/s
2
3.5 m/s
2
with metal mow-
ing attachment 2.0 m/s
2
2.0 m/s
2
