Stihl MS 440 Service Manual

63MS 440, MS 440 C
: Pull the pickup body (1) off the
suction hose (2).
Reassemble in the reverse
sequence.
VA
176RA235
21
: Insert the suction hose in the
crankcase.
– Lubricate grommet with a little oil.
: Use a blunt tool to push the
suction hose into the crankcase
so that the tab locates in its seat
VA
176RA236
at the bottom right (arrow).
A valve is installed in the tank wall to
keep internal tank pressure equal to
atmospheric pressure.
Valve cleaning
– Remove the oil tank cap.
– Drain the oil tank.
Collect chain oil in a clean container
or dispose of it properly at an
approved disposal site.
– Remove the inner side plate –
b 5.4.2
: Blow the valve (1) clear with
compressed air (from outside to
inside of tank).
– Flush out the oil tank.
– Fit the inner side plate – b 5.4.2
VA
175RA021
1
– Screw in the oil tank cap.
– Remove the oil tank cap.
– Remove the inner side plate –
b 5.4.2
: Use a 5 mm (0.20 in) drift to
carefully drive the valve out of its
seat from the inside of the tank.
VA
176RA242
: Use a 7 mm (0.28 in) drift to
carefully press home the valve
from outside until it is about
a = 1 mm (0.04 in) below the
housing face.
Reassemble all other parts in the
reverse sequence.
VA
176RA243
a
11.2 Valve
11.2.1 Cleaning
11.2.2 Replacing

Stihl MS 440 Specifications

General

Displacement	70.7 cc
Chain Pitch	3/8"
Ignition system	Electronic
Starter	Recoil starter
Vibration reduction	Anti-vibration system
Weight (without bar and chain)	6.4 kg
Fuel tank volume	0.73 L
Oil Capacity	0.36 L
Guide Bar Length	40-63 cm
Guide Bar Length (recommended)	40-71 cm (16-28 in)
