Stihl MS 440 Service Manual

75MS 440, MS 440 C
: Pull the pickup body off the fuel
hose.
– Fit a new pickup body.
Install in the reverse sequence.
VA
176RA298
– Remove carburetor – b 12.2.1
– Remove pickup body – b 12.6
: Pull the fuel hose (arrow) out of
its retainer in the tank.
VA
176RA299
: Pry the flange of the fuel hose out
of the fuel tank.
VA
176RA300
: Pull out the fuel hose.
Install in the reverse sequence.
– Lightly coat the bead of the fuel
hose with a little oil.
: The flat edge (1) of the bead must
VA
176RA301
1
rest against the tank housing.
12.7 Fuel Hose

Stihl MS 440 Specifications

General

Displacement	70.7 cc
Chain Pitch	3/8"
Ignition system	Electronic
Starter	Recoil starter
Vibration reduction	Anti-vibration system
Weight (without bar and chain)	6.4 kg
Fuel tank volume	0.73 L
Oil Capacity	0.36 L
Guide Bar Length	40-63 cm
Guide Bar Length (recommended)	40-71 cm (16-28 in)
