89MS 440, MS 440 C
15. Special Servicing Tools
No. Part Name Part No. Application Rem.
1 Locking strip 0000 893 5903 Blocking the crankshaft
2 Sealing plate 0000 855 8106 Sealing exhaust port
3 Wooden assembly block 1108 893 4800 Fitting piston
4 Clamping strap 0000 893 2600 Compressing piston rings
5 Test flange 1128 850 4200 Leakage test
6 - Bushing 0000 963 1008 Supplement to test flange
1106 850 4201
7 Carburetor and crankcase tester 1106 850 2905 Testing carburetor and crankcase for
leaks
8 Vacuum pump 0000 850 3501 Testing crankcase for leaks, checking
tank vent
9 - Nipple 0000 855 9200 Testing carburetor for leaks
10 - Fuel line 1110 141 8600 Testing carburetor for leaks
11 - Plug 1122 025 2200
12 Puller 5910 890 4400 Removing oil seals
13 Jaws (No. 3.1 + 4) 0000 893 3706 Removing oil seal(s)
14 Jaws (No. 6) 0000 893 3711 Removing oil seal(s)
15 Installing tool 1128 890 3900 Installing oil seal (starter side)
16 Installing sleeve 1122 893 4600 Protecting oil seal (clutch side)
17 Press sleeve 1118 893 2401 Installing oil seal (clutch side)
18 Assembly drift 1111 893 4700 Removing and installing the piston pin
19 Installing tool 12 5910 890 2212 Fitting hookless snap rings in piston
20 Stud puller M8 5910 893 0501 Removing bar mounting studs
21 Installing tool 1116 893 4800 Rewinding the rewind spring
22 Setting gauge 1111 890 6400 Setting air gap between ignition module
and flywheel
23 Hook 5910 893 8800 Removing pickup body
24 Assembly stand 5910 890 3100 Holding saw for servicing / repairs
25 Service tool AS 5910 890 2005 Removing and installing crankshaft
26 Assembly tube 1117 890 0900 Detaching and attaching clutch springs
27 Service tool AS (set) 5910 007 2205 Removing crankshaft (clutch side)
28 Screw sleeve 5910 893 2420 Installing crankshaft
29 Service tool ZS (set) 5910 007 2220 Removing crankshaft (starter side)
30 Screw sleeve 5910 893 2409 Pulling crankcase halves together
31 Puller 5910 890 4500 Removing limiter caps
