Dimensions
4.34 Aisle width with 800 x 1200 mm pallet along forks Ast (mm) 2062
4.35 Turning radius Wa (mm) 1390
Performance data
5.1 Driving speed, full load/no load km/h 4.0/4.5
5.2 Lifting speed, full load/no load m/s 0.02/0.025
5.3 Lowering speed, full load/no load m/s 0.06/0.03
5.8 Maximum climbing ability, with/without load % 4/10
5.9 Acceleration time, with/without load s n/a
5.10 Brake type Electromagnetic
Drive
6.1 Traction motor rating S2 60 min kW 0.65
6.2 Lifting motor rating at S3 15% kW 0.5
6.3 Battery according to DIN 43531/35/36 A, B, C, no Lithium battery
6.4 Battery voltage, nominal capacity K5 V/Ah 24/20
6.5 Battery weight (± 10%) kg 3.7
6.6 Energy consumption according to VDI cycle kW/h n/a
Other
8.1 Drive control method DC
8.4 Noise level at operator’s ear dB(A) <74
Technical data
6
Technical datasheet
98 5001 801 1505 EN - 12/2019
