Still ECH 12 User Manual

Technical datasheet
Description
1.1 Manufacturer Still
1.2 Model ECH 12
1.3
Drive type:Battery, diesel, petrol, LP gas, mains
power
Battery
1.4 Operation Pedestrian
1.5 Nominal loading capacity Q (kg) 1200
1.6 Load centre c (mm) 600
1.8 Axle centre to fork face x (mm) 950 (880)
1.9 Wheelbase y (mm) 1190 (1120)
Weight
2.1 Service weight kg 130
2.2 Axle load with load, drive side/load side (±10%) kg 420/910
2.3 Axle load without load, drive side/load side (±10%) kg 110/20
Wheels
3.1 Tyres:pneumatic, polyurethane, rubber PU/PU
3.2 Drive wheel sizes
Ø x w
(mm)
210x70
3.3 Load wheel specifications
Ø x w
(mm)
80x60
3.5 Wheels, number drive side/load side (x=traction) 1x+/4
Dimensions
4.4 Lift height h3 (mm) 110
4.9 Tiller height, travel position (min./max.) h14 (mm) 800/1190
4.15 Fork height, lowered h13 (mm) 80
4.19 Overall length l1 (mm) 1540
4.20 Length to fork face l2 (mm) 390
4.21 Total width
b1/b2
(mm)
560 (685)
4.22 Dimensions of forks s/e/l (mm) 53x150x1150
4.25 Fork spread (outside of forks) b5 (mm) 560 (685)
4.32 Ground clearance at centre of wheelbase, with load m2 (mm) 27
Technical data
6
Technical datasheet
975001 801 1505 EN - 12/2019

Still ECH 12 Specifications

General

Brand	Still
Model	ECH 12
Category	Trucks
Language	English
