Single load wheels
– Use a knockout pin to remove the spiral
slotted spring pin (1).
– Tap out the wheel pin spindle from the side.
– Remove the wheel (2) and bearing assem-
bly (3).
Changing the hydraulic oil
– Remove the hydraulic station protective
covers on both sides.
Maintenance
5
Essential maintenance
915001 801 1505 EN - 12/2019
