– Remove the three battery cables shown in
the image(5).
– Remove the battery(6).
NOTE
Pay attention to the operation of the battery to
avoid short circuits.
Installing the battery
– Install the batteries in reverse order, paying
attention to the location where the batteries
are installed and whether the wiring is cor-
rect.
NOTE
Route the battery cable so that it is not trap-
ped when the battery is inserted.
Maintenance
5
Maintenance work
76 50028011505 EN - 03/2022 - 06
