Still ECV 10 C - Check the Hydraulic Oil Level

Lubricant
Location
code
Oil name Model no. Amount added Comment
A
Antifriction hydraulic
oil
L-HM46
Lift height 1600 mm: 3.8 L
Lift height 2000 mm:3.8L
Lift height 2300 mm:4.0L
Lift height 2500 mm:4.2L
Lift height 2700 mm:4.2L
Lift height 3000 mm:4.5L
Lift height 3300 mm:4.8L
Lift height 3600 mm:4.8L
Hydraulic
system
Antifriction hydraulic
oil (cold stores)
L-HV32
B Multi-purpose grease
Polylub
GA352P
As appropriate
Sliding sur-
faces
C
Moly lithium grease
no. 3
- 100 g
Transmis-
sion
Table for lubrication of sliding surfaces
Code Position used
L1 Caster
L2 Rollers
L3 Channel and rollers
L4 Chains
L5 Steering bearing
L6 Drive wheel
Check the hydraulic oil level
NOTE
If there are popping noises coming from the
tubing when lifting, this indicates that the hy-
draulic oil is insufficient and should be prompt-
ly replenished.
CAUTION
Do not add hydraulic oil that contains impurities.
– Fully lower the mast.
– Press the emergency off switch.
– Remove the front hood.
Maintenance
5
Maintenance work
78 50028011505 EN - 03/2022 - 06
