6. Clean the filter with a hairdryer or the
dust brush (Refer Fig 8 and Fig 9).
7. After cleaning, you can assemble it
as it was before.
8. To change the dust filter, press the
semi-circle bracket with one hand
to release the fastener from the
filter screen. Remove the filter
with the other hand and then
replace with a new filter (Refer Fig 10).
5. The velcro mop base can be attached to the dust filter bracket. To replace
the dustbin, ensure that the mop is not attached. Uplug the right and left
fastener of the velcro mop base on the dust filter bracket. (Refer Fig 11 and
Fig 12). All parts should be re-assembled as they were before being
disassembled.
20
1800 898 750
service@wkfe.com.hk
Telephone:
Email:
Other Useful Information Cont.
Figure 9
Figure 8
Figure 10
Figure 11 Figure 12
