Cleaning the Dustbin and Filters
1. Extract the dustbin by pressing
the key on top of the vacuum
(Refer Fig 1 and Fig 2).
2. First empty the dust into a bin, and
then clean the inside with the dust
brush supplied (Refer Fig 3).
3. Press the small button and the
air outlet will pop out
automatically (Refer Fig 4).
Don’t clean the air outlet unit in water!
4. Remove the air outlet unit and then clean
the air inlet/outlet with the dust brush
(Refer Fig 5).
5. Open the dust filter bracket
and the dust filter will slide open
(Refer Fig 6). Take out the dust filter
and then clean the dustbin in water
(Refer Fig 7).
Don’t use the velcro mop base and mop pad on carpet or uneven
ground.
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
Figure 1 Figure 2
