4.3 Avaialable Power Down Modes
Power Down Mode
Conditions
Power Consumption
No Power Down
normal operation
(idle)
Power Down deactivated (S409=0)
Page/inquiry scan enabled (S316=3)
DTR active (0V on LV-TTL level)
20pprox.. 2.5 mA
Power Down
Power Down active (S409=1)
Page scan enabled (S316=2)
Accept incoming call
when DTR is inactive (AT&D4)
DTR inactive (3.3V on LV-TTL level)
20pprox.. 1.1 mA
Deep Sleep
Power Down active (S409=1)
No page/inquiry scan (S316=0)
DTR inactive (3.3V on LV-TTL level)
20pprox.. 0.04 mA
RESET state
20pprox.. 2.3 mA
