Stollmann BlueMod+B20 User Manual

BlueMod+B20/BT2.1
User Guide
Release r03 www.stollmann.de Page 8 of 38
2.2 HID Connection Examples
The following flow charts will give an example for the configuration and connection
establishment using the BlueMod+B20 and an iPhone with and without SSP.
Onto these flow charts the local Bluetooth device (BT device A) is a BlueMod+B20.
The destination is a iPhone with iOS 5.x.
The “Application” part will simulate the device at the end (DTE) which communicates
to the local Bluetooth device with configuration commands.
The box called “AIR” will signal which part of communication will be transmitted over
Bluetooth to the destination side.
The configuration commands and responses within the flow charts are described in
the BlueMod+B20/BT2.1 AT Command Reference.
2.2.1 Connection Example with iPhone (SSP “Just Works”)
