7.5 OPPC Transmission Examples with BlueMod+B20
The following flow charts will give examples with different OPPC transmission results
between the BlueMod+B20 and the reference device. In our situation the reference
device is a smart phone.
The “Application” part will simulate the device at the end (DTE) which communicates to
the local Bluetooth device or the application within the smart phone.
The box called “AIR” will signal which part of communication will be transmitted over
Bluetooth to the destination side.
The configuration commands and responses within the flow charts are described in the
BlueMod+B20/BT2.1 AT Command Reference.
