4. S800 Surveying System
S800 surveying system consists of three main components, namely receiver,
handheld and accessories. In the following parts are their introductions.
4.1 S800 Receiver
4.1.1 Receiver appearance
The receiver’s dimension is 146mm*146mm*76mm, weighting 1.2kg, with its
appearance as illustrated in Figure 4-1. The front side is control panel,
consisting of 1 power button and 4 indicators. The bottom are interfaces of
UHF antenna and cables.
Figure 4-1 S800 Receiver
