Fig. 2
D 51: Circuit changeover with twin break
electrically isolated contact bridges
G 54: Circuit breaker switch
E 52: Circuit changeover quick action with
twin break contact bridges electrically iso-
lated from each other
1, 2, 3, 4,
13, 14,
21, 22
Connection points
F 53: Circuit changeover button with twin
break contact bridges electrically isolated
from each other
