6 Assembly
6.1 Special safety guidelines
CAUTION
Risk of accidents caused by live components
For all work on components or individual parts, the machine must be switched off and secured
against non-intended reconnection.
► Check that the machine is de-energised before beginning the work.
CAUTION
Risk of accidents caused by rotating components
Risk of entanglement in the area between the GTES and the machine due to rotating components.
► The operator must install a covering above the connecting flange.
NOTICE
Damage to the machine due to the incorrect adjustment of the GTES
When the GTES has not been adjusted, traverse movements of the machine can lead to damage.
► Before commissioning the machine, always adjust the GTES first in accordance with the specifica-
tions in the mounting/operating instructions.
The installation regulations applicable on-site and the mounting instructions of the machine manufacturer must
be observed.
6.2 Conditions for assembly and fixing
Required assembly space:
• basic cover height
Assembly sequence:
• Mechanical assembly, see section 6.3.
• Electrical connection, see section 6.4.
• Switching point adjustment, see section 6.6.
• Completion of the housing, see section 6.7.
6.2.1 Special tools
A special tool is not necessary for standard designs.
6.2.2 Assembly precision
Avoid misalignments and offsets between the drive shaft of the GTES and the machine.
25
Mounting/operating instructions Gear limit switch Type series HGE • No. 152-00000 F • 10/2017
